Satellite signal loss

0.025deg /5min

0.15 deg /1h

Roll attitude accuracy

≤0.8 deg

Pitch attitude accuracy

≤0.8 deg

Outages GPS

Speed accuracy

0.1m/s

Single point positioning

DGPS 0.5m /RTK 2cm

Orientation accuracy

0.1deg，（2m base wire）

Measurement range

Azimuth

±180 deg

Roll angle

±90 deg

Pitch angle

±90 deg

Angular velocity

±300 deg/s

Acceleration

±4 g

Interface characteristics

Power

+9~+36 Vdc, ≤8 W @ 24Vdc

Electrical Interface

RS422

Data update rate

100 Hz @ 115,200 baud rate

Use environment

Operating temperature

-40°C ~ +60°C

Storage temperature

-55°C ~ +85°C

Mechanical

Size

153 ×142 × 115 mm

（ Designable）

Weight

≤1770 g

Connector

Y11P-1210ZK10
