Measurement axis

Mutually perpendicular

X-Y-Z

Accuracy（°）

Room temperature

±0.01

±0.02

±0.03

Resolution（°）

Completely still

0.001

0.001

0.001

Zero temperature drift （°）

-40～85℃

±0.001

±0.001

±0.001

Cross axis error （°/℃）

25℃

0.01

0.01

0.01

Output frequency （Hz°）

Up to 100

Other output data

Temperature, Battery Voltage

Automatic sleep mode

Acceptable

Timed wake up

Acceptable

Exercise wake

Acceptable

Electromagnetic compatibility

According to GBT17626

Insulation resistance

≥100 MΩ

Impact resistance

2000g，0.5ms，3 times /axis

Dimensions

L105.2*W85*H76 (mm) (without antenna)

Weight

＜500g

Disposable dry cell voltage

3.6VDC

Working current

50mA (Average value)

Stand-by current

6μA(Typical values)

Rechargeable battery capacity

6000mAH

Disposable dry cell battery capacity

19000mAH

Communication distance

Maximum: 5Km

Operating temperature

-40℃~85℃

LoRa band

410.125~493.125MHz

Standard antenna height

110mm

Standard antenna gain

2.5DBI

Limited Data

Every frame 20Byte

Reliability

The mean time between failures (MTBF) is not less than 50,000 hours

Ultra-low power consumption design, including automatic sleep mode, timing wake-up, sports wake-up
