Heading accuracy

1°

Tilt range

Pitch±90º，Roll±180º

Gyro

Resolution

0.01°

Range

±400°/sec

Bias stability at full temperature

30 °/h（10s,1σ)

ARW

＜0.1 °/√h

Scale factor non-linearity

≤100ppm（1σ）

Scale factor repeatability

≤100ppm（1σ）

Bandwidth

100Hz

Accelerometer

Range: X, Y, Z

±3.6 g

Bias stability

0.001mg（25℃，100s，1σ）

0.01mg（25℃，10s，1σ）

Interface characteristics

Communication mode

RS232/RS485/TLL

Maximum output frequency

100Hz

MTBF

≥90000 h/time

EMC

According to GBT17626

Insulation resistance

≥100 MΩ

Impact resistance

2000g，0.5ms，3 times/axis

Weight (with cable)

280g
