Thermal Imaging

Detector Type

Vanadium Oxide Uncooled Focal Plane Detector

Image Resolution

384*288

Element Size

17μm

Detector NETD

≦50mK@25℃

Response Band

8 ~14μm

Package Type

Ceramic Package

Visible light

Sensor

1/2.8”CMOS

Graphic Resolution

2592× 1536

Minimum Illumination

0.002Lux/F1.5(Colour) , 0.0002Lux/F1.5(B/W)

Infrared fill light

Infrared fill light 30 metres

Digital zoom

Support

Automatic Gain Control

ICR Infrared Filter

Image handling

Digital Video

H264

Master Streaming Image

Visible light： 25fps(2592× 1536,1920× 1080,1280×720)

Start-up time

10s

Image Processing

Non-uniformity correction, intelligent gain control, digital detail mixing enhancement, 3D noise reduction

Colour palette

Support 10 colour palettes such as Black Hot, White Hot, Iron Red, Rainbow, etc./Customizable

Image Mirroring

Left, right, up, down, centre

Function

Abnormal temperature alarm

Support temperature abnormality alarm

Temperature measurement function

Full-screen maximum and minimum temperature positioning

Support 1 line, 9 frames, 10 points, 2 irregular areas, 2 elliptical areas temperature measurement

Temperature range: -20℃~150℃ (extendable to 550℃)@-10~50℃.

Temperature measurement accuracy: ±2℃ or ±2% (take the greater value) no black body

Support reflective temperature, atmospheric temperature setting, target distance correction, support emissivity correction

Alarm

IP conflict, linkage alarm function

Internet

Ethernet Types

100Mbps

Network Protocols

IPV4,  HTTP,  FTP,  RTSP,  RTCP,  RTP,  TCP,  UDP

Concurrent Access

20 way

Security Mode

Authorised users and passwords

Access Standard

Private SDK, ONVIF, GB/T28181

Data interface

Compressed Data

H264 video, standard JPEG images

System Integration

Communication Interfaces

RJ45, Network Transmission

One RS485

PTZ Control

Pelco-D protocol, RS-485 interface

Alarm Input/Output

2 in/2 out

Power supply

Power Supply Range

DC12V

Typical Power Consumption

2.2W

Physical characteristics

Product Size

96mm*108mm*232mm

Weight (without accessories)

845.5g(without stand)

Waterproof rating

IP66

Environmental adaptability

Working Temperature/°C

-30℃～+60℃

Storage Temperature/°C

-45℃～+75℃

Humidity/RH

≤95%
