Operating   system

System   type

Linux-5.4.0

Linux-5.4.0

Storage

Onboard   storage

32GB FLASH

32GB FLASH

MicroSD card

Supported   (up to 32G)

Supported   (up to 32G)

Display

Display resolution

1280*800

1280*800

Display Size

10.1   inches

10.1   inches

Input   output interface

Ethernet

Two   gigabit Ethernet ports

Two   gigabit Ethernet ports

wireless

4G (all   network connectivity)

4G (all   network connectivity)

USB

2-way   standard USB interface

2-way   standard USB interface

Including 1 USB OTG interface (debugging   interface)

Including 1 USB OTG interface (debugging   interface)

Serial port

10 standard three wire RS232, 3 standard   two wire RS485

10 standard three wire RS232, 3 standard   two wire RS485

Switching input

8   channels (0-5V input)

8   channels (0-5V input)

Analog input

8 channels 16 bit analog input signal

8 channels 16 bit analog input signal

4-20mA compatible with 0-5V, measurement   error ≤ 0.1%

4-20mA compatible with 0-5V, measurement   error ≤ 0.1%

Switching output

7 relay   outputs

7 relay   outputs

Other

size

315x400x130mm

315x400x130mm

Power supply

AC220V/50HZ

AC220V/50HZ

Backup power supply

Built in 112V 10400mA/h lithium battery   pack

Built in 112V 10400mA/h lithium battery   pack

Battery   life≥8h

Battery   life≥8h

Work environment

Temperature:-10~55℃relative humidity:≤90%RH

Temperature:-10~55℃relative humidity:≤90%RH

Power

＜8W

＜8W

Exhibition

Sign   in

√

√

real-time   data

√

√

historical   data

√

√

statistical   data

√

√

Display of data acquisition   instrument configuration information

√

√

Operation   log

√

√

Local   configuration

Upload   Configuration

√

√

Collection   Configuration

√

√

Time   Configuration

√

√

Alarm   threshold

√

√

Reverse   control configuration

√

√

Remote   upgrade

Remote   serial port debugging

√

√

Remote   data upgrade

√

√

Remote update of protocol   library

√

√

Data   reissue

Manual   reissue

√

√

Automatic   reissue

√

√

Collocation method

Manual   configuration, export configuration

√

√

Import   configuration, export configuration

√

√

Dynamic   control

√

√

Transmit   every change

×

√

Camera and access control   directly enter

×

√
