Power voltage(V)

12

36

Working Current (mA)

No load

20

50

60

Output load (Ω)

Max

500

Operating Temperature (℃)

-40

25

85

Storage Temperature (℃)

-55

25

100

Measurement axis

Mutually perpendicular

X-Y

Accuracy (°)

Room temperature

0.01

Resolution (°)

Completely still

0.001

Zero bias (°/℃)

-40~85℃

±0.01

Cross axis error(°)

0.01

Output frequency (Hz）

 100

Zero current output (V)

10(0-20)；12(4-20)；12(0-24)

Full-scale output current range (V)

4-20  (0-20 optional)  (0-24 optional)

Mean time between failures MTBF

≥90000 h

Electromagnetic compatibility

According to GBT17626

Insulation resistance

≥100 MΩ

Impact resistance

2000g，0.5ms，3 times/axis
