Resolution

0.1°

Repeatability

0.05°

Compass tilt parameters

Pitch accuracy

0.1º

Roll accuracy

0.1°（  Pitch <65°）

0.2°（  Pitch <80°）

0.5°（  Pitch <86°）

Resolution

0.01°

Tilt range

Pitch ±90°；Roll±180°

Calibration

Hard magnetic calibration

Yes

Soft magnetic calibration

Yes

Limited tilt user calibration

Yes

Physical properties

Dimension

L114 x W20 x H20 (mm)

Weight

100g

Output form

RS232/485/TTL Interface

Interface characteristics

Start-up delay

<3s

Maximum output frequency

50Hz

RS232 communication rate

2400 to 115200 Baud rate

Environment

Anti-vibration performance

2000g
