●Three-axis accelerometer three-axis magnetometer
●Static measurements accuracy: 0.2°
●Offset tracking algorithm eliminates drift
●High accuracy, low cost
●Operating temperature：-40℃~+85℃
●Small size：L107 x W38 x H25 (mm)
●Hard magnetic, soft magnetic and tilt compensation
●Standard RS232/RS485/TTL output interface
Shared：
Compass heading parameter | Heading accuracy | ±0.2 RMS（Horizontal use） ＜0.5 RMS（Pitch<30°） | |
Resolution | 0.001° | ||
Repeatability | 0.05° | ||
Compass tilt parameter | Pitch accuracy | 0.01° | |
Roll accuracy | 0.01° | ||
Resolution | 0.001° | ||
Tilt range | ±30° | ||
Physical specifications | Size | L107 x W38 x H25 (mm) | |
Weight | 100g | ||
Output form | RS232/485/TTL interface | ||
Interface specifications | Start-up delay | <3s | |
Maximum output frequency | 50Hz | ||
RS232 communication rate | 2400 to 115200 baud rates | ||
Environment | Anti-vibration performance | 2000g |
Product size：L107 x W38 x H25（mm）
-
