Measurement axis

Mutually perpendicular

X-Y

X-Y

Accuracy (°)

Room temperature

0.001

0.003

Cross axis error (°)

-40~85℃

0.001

0.003

Resolution (°)

Completely still

0.0001

Zero bias (°/℃)

-40~85℃

±0.0003

Start-up time

＜3s

Output frequency (Hz)

5-100Hz adjustable

Up to 100

Baud rate

Adjustable

2400~115200

Mean time between failures MTBF

≥90000 h/time

Electromagnetic compatibility

According to GBT17626

Insulation resistance

≥100MΩ

Weight (g)

 320 (metal plug) / 350 (airline plug)

Electrostatic Discharge (ESD)

IEC 61000-4-2 Class IV

Contact discharge 8KV, air discharge 15KV

Fast transient burst immunity

IEC 61000-4-4 Class IV

Repetition frequency 5kHz, positive and negative power supply 4KV, signal line 2KV
