● Dual axis inclination monitoring
● Alarm threshold can be set arbitrarily
● Single line output alarm
● Wide voltage input 9～36V
● Supports external zero setting function
● High vibration resistance >2000g
● high resolution：0.01°
Shared：
Parameter | Condition | Min | Typ | Max | |||
Power voltage(V) | 9 | 12 | 36 | ||||
Working current(mA) | Horizontal no-load | 40 | |||||
Operating temperature(℃) | -40 | 85 | |||||
Storage temperature(℃) | -55 | 100 |
Parameter | Condition | DIS342 | |
Measurement Range（°） | ±90 | ||
Accuracy（°） | Dynamic 2°/ Static 0.1° | ||
Measurement axis | X、Y | ||
Alarm axis | X、Y | ||
Zero temperature drift（°/℃） | -40~85℃ | ±0.01 | |
Response frequency (Hz） | 100 | ||
Communication cable | 10-core cable, single 0.15mm² | ||
Weight (g) | About 220（Cable 1.5m,without package） |
| Application | |
● Hydraulic lift table ● High voltage power line tower monitoring ● Aerial work vehicle | ● Cloud platform leveling ● Tilt-based |
-
