●Resolution: 0.001°.
●Dual-axis inclination measurement with a range of ±90°.
●Magnetic switch
●Data can be transferred to the cloud
●Remote online upgrade
●Three-axis acceleration
●IP68 waterproof rating
●Accuracy 0.005°
●Three-axis tilt
●Tim
Shared：
Monitoring items | Range | Accuracy | Unit | ||
X,Y,Z axis angle
| 0~30 | 0.005 | ° | ||
30~60 | 0.006 | ° | |||
60~90 | 0.007 | ° | |||
X,Y,Z axis acceleration | ±2000 | 1 | mg | ||
Other reported data | Temperature, Battery Voltage, 4G Signal Strength | ||||
Frequency band information | LTE | ||||
LTE-FDD | B1/B3/B5/B8 | ||||
LTE-TDD | B34/B38/B39/B40/B41 | ||||
USIM card | Nano-SIM card (small card), support 4G full network communication, user replaceable | ||||
Free Maintenance Time | >3 years | ||||
Weight | <500g | ||||
Dimension | L105.2*W85*H76 (mm) (without antenna) | ||||
Standard Antenna Height | 28mm (without antenna cap); 40.94mm (with antenna cap) | ||||
Standard Antenna Gain | 12DBI | ||||
Power connector | Rechargeable Battery Charging Voltage | 8.4VDC |
Disposable Dry Battery Voltage | 3.6VDC | |
Standby Current | 6μA (typical) | |
Operating Current | 50mA (average) | |
Rechargeable Battery Capacity | 6000mAH | |
Disposable Dry Battery Capacity | 19000mAH | |
Operating temperature | -40℃~85℃ |
-
